✓Standard equipment configuration
✓Electrical system: 48V DC, 8V deep cycle storage batteries
✓Speed control: solid state continuously variable separately excited speed controller - Curtis, chopper SEM-1C, electronic forward-neutral-reverse shifting
✓Regenerative pedal down and or pedal up braking
✓Non-contact inductive throttle sensor
✓Enhanced hill climbing ability
✓Full torque, reduce speed reverse
✓Transaxle: high efficiency helical gears, ratio: 12.44:1
✓Brakes: mechanical drum brake on each rear wheel with self-adjuster, non-asbestos braking plate, auto releasing the parking lock
✓Suspension: independent and automatically suspension with self balance
✓Steering: self-compensating single reduction rack and pinion
✓Speed: 18-24km/h
✓Contour dimensions: 4,100 x 1,160 x 1,800mm
✓Weight (battery excluded): 420kg
✓Max. speed: 18 - 20km/h
✓Max. continuous mileage: 80 - 100km
✓Slope climbing capability (full load): 20%
✓Min. ground clearance: 97mm
✓Min. turning radius: 4.8m
✓Max. noise: <50dB
✓Axle distance: 1,635mm
✓Wheel base (front/rear): 870mm/980mm
✓Storage battery capacity: 145Ah
✓Voltage: 8V x 6
✓Motor (power/voltage): 3.7kW/48V DC separately excited motors
✓Brake system: mechanical drum brake on each rear wheel with self adjuster, non-asbestos braking plate, auto releasing the parking lock
✓Tyre: 18 x 8.5 - 8
✓Charger: fully automatic high frequency intelligent charger
✓Seat capacity: for 6 persons
✓Maximum gradient: 30%
✓Electrical control way: change speed by chopping wave
✓Controller: 48V, 350A
✦
Body and finish: Industrial plastic ABS 747 and PP with injection molded, molded-in color with automotive color coat finish.
✦
Chassis: Welded high yield strength tubular steel with liquid coat paint.
✦
Safety: Dash mounted key switch, reverse warming indicator, accelerator pedal, parking pedal, innovative hand holder/handgrip.
✦
Dash panel: Tee, ball, and 4-position drink holder, volt indicator, easy to touch and operate.
✦
Performance options: Selectable top speed and pedal up braking characteristics.
✦
Diagnostic mode: Time saving troubleshooting capability.
Frequently Asked Questions
QWhat is the seating capacity of this electric golf cart?
This model is designed to comfortably accommodate up to 6 persons (LT-A4+2 configuration).
QWhat are the battery specifications and range capability?
The golf cart operates on a 48V DC electrical system with six 8V deep cycle storage batteries (145Ah capacity). It offers a maximum continuous driving mileage of 80 to 100km on a full charge.
QWhat is the maximum speed and hill-climbing capability?
The maximum speed ranges between 18 to 24 km/h. It features enhanced hill-climbing capability with a slope climbing gradient capacity of 20% to 30%.
QWhat kind of braking system does this golf cart use?
It features a mechanical drum brake on each rear wheel equipped with a self-adjuster, non-asbestos braking plate, and an automatic releasing parking lock.
QHow are the body and chassis constructed?
The body is made of industrial plastic ABS 747 and PP with injection molding and automotive color coat finish. The chassis is constructed of welded high yield strength tubular steel finished with liquid coat paint.
QDoes the electric golf cart come with a battery charger?
Yes, it is equipped with a fully automatic high frequency intelligent charger for convenient and optimal battery maintenance.
