| Vehicle Parameter | Single-row Forward | Double-row Forward | Front and Rear 1+1 | Three-row Forward | Three-row 2+1 |
|---|---|---|---|---|---|
| Dimensions (mm) | 2400 - 1350 - 1900 | 3180 - 1350 - 1900 | 2980 - 1350 - 1900 | 4080 - 1350 - 1900 | 3880 - 1350 - 1900 |
| Electronic Control | Standard 60V Yingboer controller, optional 72V Yingboer controller | ||||
| Battery | Standard 60V 100Ah maintenance-free battery, optional 72V 120Ah / 150Ah maintenance-free battery, lithium battery options (120A / 150A) | ||||
| Motor | Standard 3.5KW brand-name motor, optional 4KW / 5KW / 7.5KW / 11KW brand-name motor | ||||
| Driving Speed | 30 km/h | ||||
| Rated Passengers | 2 persons | 4 persons | 4 persons | 6 persons | 6 persons |
| Charging Time | 7 - 10 hours (at 80% discharge rate) | ||||
| Curb Weight | 450kg | 590kg | 590kg | 670kg | 670kg |
| Max Climbing Capacity | 17% | 17% | 17% | 17% | 17% |
| Range | About 80 - 100KM (battery size affects the range) | ||||
| Body Frame | Steel frame + electrophoresis phosphating anti-rust treatment + automobile baking paint | ||||
| Front Suspension | McPherson independent suspension | ||||
| Rear Suspension | Integral rear axle (12.49) + high-strength leaf spring + cartridge hydraulic shock absorber | ||||
| Steering System | Rack and pinion steering gear | ||||
| Wheels | Special ball wheels 205*50 - 10 | ||||
